VR-TAK: VIRTUAL REALITY TACTICAL ASSAULT KIT

Virtual Reality Application for Mission Planning and Command and Control

ARA’s VR-TAK (Virtual Reality Tactical Assault Kit) is an innovative Virtual Reality (VR) tool developed for the modern warfighter, improving mission planning and rehearsal, and situational awareness.

VR-TAK’s software uses real-world geo-registered terrain data to create collaborative, geographically accurate 3D environments, helping military operators train as they fight. VR-TAK focuses on interoperating new training solutions with existing ones, significantly reducing the learning curve for Soldiers in the field.

VR-TAK Features

  • Part of the TAK ecosystem
    • Follows the same look and feel to minimize learning curve
    • Shares data with other TAK products via COTs
  • Supports most popular VR headset systems, but can also be used in desktop mode (keyboard and mouse), and gamepads
  • Supports multiple terrain and dataset formats
  • Plugin SDK to support 3rd party UE5 plugin development
  • Virtual Tactical Operations Center (VTOC) with web boards and Multi-User Collaboration (MUC)

Hardware requirements

  • OS: Windows 10 or later
  • Processor: Intel Core i5-4590/AMD FX 8350 equivalent or better
  • Memory: 16 GB RAM minimum
  • Dedicated Graphics Card: NVIDIA GeForce GTX 970, AMD Radeon R9 290 equivalent or better

VR headsets supported

You do not need a VR headset to run VR-TAK, but in case you have one, these are the headsets we currently support:

  • HTC VIVE, VIVE Pro, and Valve Index
  • VIVE Cosmos requires VIVE software
  • Oculus Rift S and S2
  • Oculus Quest, Quest 2, and Quest 3
  • Valve Index (SteamVR)
  • Varjo (SteamVR)

Dataset formats currently supported

  • Terrain Elevation -DTED, Quantized Mesh, Mapbox
  • 3D Tile format (gltf, b3dm, glb, geojson (polygons only)
  • Pointclouds (xyz, pts, txt, las, lax, e57)
  • Several raw mesh formats such as OBJ, FBX, DAE (Collada), 3DS, BLEND, etc.
  • Geo-tagged datasets from services such as BuckEye, Context Capture, FG3D, Hivemapper, CORE 3D, NearMap3D, PeARL, etc.
  • KML/KMZ files
  • Mapbox vector tiles

VR-TAK is an innovative VR tool for improved mission planning and rehearsal and better situational awareness.
